Product Description
| Task | Measuring - Level Protecting objects - Buildings and grounds Protecting objects - Valuable items Protecting objects - Vehicles Protecting objects - Infrastructure Localizing, navigating and guiding - Localizing Determining position - 2D position determination |
| Application | Outdoor |
| Light source | Infrared (905 nm) |
| Laser class | 1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Aperture angleHorizontal270° | |
| Scanning frequency | 25 Hz 50 Hz |
| Angular resolution | 0.25° 0.5° |
| Heating | Yes |
| Working range | 0.5 m ... 20 m |
| Scanning rangeAt 10% remission factor18 mAt 90% remission factor20 m | |
| Amount of evaluated echoes | 2 |
| Fog correction | Yes |
